◆ 전선약호 Full name  |  학습자료 2018-03-29 17:38:11
작성자  김대호 조회  8274   |   추천  241
순위 약호 내용
1 A Annealed of soft conductor. (Round, Rectangular, Strand)
2 AAI As same as A, but aluminium conductor.
3 AB Asbestose braiding wire.
4 AC Asbestose covering(Spiral).
5 ACSR Aluminium conductor (or cable) steel (galvanized) reinforced.
6 ACSR/AN As same as ACSR, but alumized steel reinforced.
7 ACSR/AW As same as ACSR, but aluminium-weld (alimoweld) steel reinforced
8 ACSR/EST As same as ACSR, but extra-strength steel reinforced
9 ACSR-MOE As same as ACSR, but PE insulated multi-cable in out-door.
10 ACSR-OC As same as ACSR, but XLPE insulated in out-door location.
11 ACSR-OE As same as ACSR, but PE insulated in out-door location.
12 ACSR-OW As same as ACSR, but PVC insulated in out-door location.
13 ADSS All Dielectric Self Supporting Optical Cable
14 AIRN Automotive high voltage insulated rubber chloroprene sheathed wire.
15 AIRV As same as AIRN, but PVC sheathed.
16 AIW Poly-amide imide enamelled wire.
17 As-C Copper conductor 99.9%, involved Ag. 08%
18 AURBS As same as AIRN, but shielded.
19 AV Automotive low-voltage PVC insulated wire.
20 AW Alumi weld (Alumo welded) wire.
21 BA Soft copper for the ribbon.
22 BC Braided copper conductor/Bare copper conductor
23 BDGC Glass double braid rectanglar copper wire.
24 BE Butyl rubber insulated PE sheathed cable.
25 BGCA Glass cambric insulated wire.
26 BL Butyl rubber insulated lead sheathed cable.
27 BLTA As same as BL, but steel tape armouring cable.
28 BN Butyl rubber insulated chloroprene sheathed cable.
29 BNCT As same as BN, but conductor is very flaxible. ( Called cabtyre, symbol CT )
30 2BNCT As same as BNCT, but grade 2.
31 3BNCT As same as BNCT, but grade 3.
32 4BNCT As same as BNCT, but grade 4.
33 BSGC As same as BDGC, S means single.
34 BSGC As same as BVTA, but PVC anti-corrosion cable.
35 BV Butyl rubber insulated PVC sheathed cable.
36 BVTA As same as BV, but steel tape armouring.
37 CA Copper-clad aluminuum wire. Chromel-alumel thermo-couple wire.
38 1CA Cambric insulated wire, grade 1.
39 2CA As same as 1CA, but grade 2.
40 CAZV High-voltage XLPE insulated AI sheathed PVC anti-corrosion cable.

순위 약호 내용
41 CB- Concreat direct buried cables.
42 CBN Control butyl rubber insulated chloroprene sheathed cable.
43 CCE Control XLPE insulated PE sheathed cable.
44 CCV Control XLPE insulated PVC sheathed cable.
45 CE XLPE insulated PE sheathed cable.
46 CEE Control PE insulated & sheathed cable.
47 CEMAZE High-voltage XLPE insulated PE sheathed, corrugated steel anti-corrosion cable.
48 CEMAZV As same as CEMAZE, but PVC anti-corrosion.
49 CET As same as CE, but triplex type.
50 CEV Control PE insulated PVC sheathed cable.
51 CEVTA As same as CEV, but steel tape armouring.
52 CEYV Control PE insulated nylon jacket PVC sheathed cable.
53 CHH Control hypalon insulated & sheathed cable.
54 CL XLPE insulated lead sheathed cable.
55 CLTA As same as CL, but steel tape armouring.
56 CLTAZV As same as CLTA, but PVC anti-corrosion.
57 CP Copper plated wire.
58 CP- Cable for telephone pair type.
59 CQ- Cable for telephone quad type.
60 CRLN Control rubber insulated lead jacket chloroprene sheathed cable.
61 CRN As same as CRLN, but not lead jacketed.
62 CRV As same as CRN, but PVC sheathed cable.
63 CS Copper clad steel wire. (involved strand conductor.)
64 CSC AS same as CS, but complext conductor.
65 CT Cabtyre cable.
66 1 CT-4 CT Rubber insulated cabtyre cable grade 1-4.
67 CTF Rubber insulated cord.
68 CTFK As same as CTF, but round type.
69 CTH Cabtyre cord for safety lamp.
70 CTHS Cabtyre cprd for telephone.
71 CV XLPE insulated PVC sheathed cable.
72 CVCT As same as CV, but cabtyre cable.
73 CVL As same as CV, but lead jacketed.
74 CVMAZE As same as CV, but corrugated steel pipe armoured PE anti-corrosion cable.
75 CVMAZV As same as CVMAZE, but PVC anti corrosion.
76 CVS Control PVC insulated & sheathed, solid type.
77 CVSTA As same as CVS, but steel type armoured cable.
78 CVT As same as CV, but triplex type.
79 CVTA As same as CVT, but steel tape armoured.
80 CVTAZV As same as CVTA, but PVC anti-corrosion.
81 CVV Control PVC insulated & sheathed cable, jacket type.
82 CVVMAZV As same as CVMAZV, but PVC insulated cable.
83 CVVS As same as CVV, but copper tape shield cable.
84 CVVSB As same as CVV, but copper wire braid shield cable.

순위 약호 내용
85 CVVTA As same as CVV, but steel tape armoured cable.
86 DAB Double asbestos braid wire.
87 1DAB 2DAB As same as DAB, but grade 1 or 2
88 DCC Double cotton covered wire. (Involved rectangular conductor.)
89 DGB Double glass braid wire.
90 DGC Double glass covered wire.
91 DSC Double silk covered wire.
92 DV Service entrance drop wire, PVC insulated.
93 DVF As same as DV, but flat type.
94 EACSR As same as ACSR, but extra strength steel used.
95 EC Electrical conductor grade.
Earth conductors
96 ECRB Elevator control rubber insulated braid cable.
97 ECRB-L As same as ECRB, but have not support wire.
98 ECRB-R As same as ECRB, but have support wire.
99 ECRN Elevator control rubber insulated chloroprene sheathed cable.
100 ECRN-H As sane as EXRN, but have support wire.
101 ECRN-L As sane as ECRBN, but have not support wire.
102 ECRV Elevator control rubber insulated PVC sheathed cable.
103 ECSB Elevator control SBR insulated braid cable.
104 ECSN As same as ECSB, but chloroprene sheathed cable.
105 ECSV As same as ECSN, but PVC sheathed cable.
106 ECVB As same as ECSB, but PVC insulated cable.
107 ECVV As same as ECVB, but PVC sheathed cable.
108 ECX PE insulated high frequency coaxial cable.
109 ECXF As same as ECX, but cord.
110 EE PE insulated & sheathed cable.
111 EFCXF Formed polyethylene insulated coaxial cord.
112 EL PE insulated lead sheathed cable.
113 ELTA As same as EL, but steel tape armoured cable.
114 EN PE insulated & nylon jacketed wire.
115 ESRB Elevator signal rubber insulated braid cable.
116 ESRN As same as ESRB, but chloroprene sheathed cable.
117 ESRV As same as ESRN, but PVC sheathed cable.
118 ESS Electronic Switching Systems
119 ESSB As same as ESRB, but SBR insulated cable.
120 ESSN As same as ESSB, but chloroprene sheathed.
121 ESSV As same as ESSN, but PVC sheathed.
122 ESVB As same as ESSB, but PVC insulated.
123 ESVV As same as ESVB, but PVC sheathed.
124 ETA PE insulated steel tape armoured cable.
125 EV PE insulated PVC sheathed cable.
126 EVCT As same as EV, but cabtyre conductor cable.
127 EVCTF As same as EVCT, but cord.
128 EVTA As same as EV, but steel tape armoured.
129 EVTAZV As same as EVTA, but PVC anti-corrosion.

순위 약호 내용
130 EVWA As same as EV, but steel tape armoured.
131 EXR Exposure rubber insulated wire.
132 EXV As same as EXR, but PVC insulated.
133 EYB PE insulated nylon braid wire.
134 EYRF As same as EYB, but round cord.
135 EYVS PE insulated nylon jacket shielded PVC sheathed cable.
136 FL Fluorescent lamp wire.
137 FR-3 Flame-resistant grade 380℃ at 15 minute, used for fire alarm & signal line.
138 FR-8 Flame-resistant grade 840℃ at 30 minute, used for power supply line.
139 GC Glass-covered wire. Rectangular type.
140 GF- Low gas pressure cable.
141 GSTACSR Gap stranded thermo-resistant ACSR
142 GT Grooved trolley wire.
143 GT-Ag As same as GT, but copper conductor involved Ag.
144 GV Used for grounding PVC insulated wire.
145 H Hard-drawn copper wire (Solid, Stranded, Strip, Rectangular)
146 HA Half hard-drawn copper wire.
147 HAAI Half hard-drawn aluminium wire.
148 HAI Hard-drawn aluminium wire.
149 HDCC Hard-drawn copper conductor.
150 HDGC H grade double glass covered rectangular copper conductor.
151 HGCA H grade glass cambric insulated wire.
152 HHCT Hypalon insulated cabtyre cable.
153 HIV High temperature (75℃) PVC insulated wire.
154 HR Heat-resistant cable. Same FR-3
155 HSGC H grade single glass covered conductor.
156 IC XLPE insulated wire.
157 IE PE insulated wire.
158 IH Hypalon insulated wire.
159 IP EPR insulated wire.
160 IV PVC (60℃) insulated wire.
161 KC Paper winding copper conductor. (Involved rectangular conductor)
162 KGB Silicone rubber insulated glass braid wire.
163 KIB High-voltage apparatus butyl insulated wire.
164 KIC As same as KIB, but XLPE insulated.
165 KIP As same as KIB, but EPR insulated.
166 KIP-C As same as KIP, but used for circuit breaker.
167 KIV Electric apparatus PVC insulated wire.
168 KTAI High-tensile heat-resistant aluminium alloy wire.
169 KT-ACSR As same as ACSR, but aluminium changed KTAI
170 KVY PVC insulated nylon jacketed wire. Used for equipment. same THHN
171 L- Used for lead wire.

순위 약호 내용
172 LBN Butyl insulated chloroprene sheathed, used for lead wire.
173 LCX Leakage coaxial cable.
174 LH Hard drawn copper stranded conductor, used for arrestor.
175 LZS Silk winding litz wire.
176 LZT Teflon winding litz wire.
177 M- Used for mining of multi-cable.
178 MI Mineral insulated cable.
179 MRB Heat resistant rubber insulated wire.
180 MRBM As same as MRB, but multi-cable.
181 MVVS Micro-phone PVC insulated & sheathed shielded cable.
182 NEV PE insulated PVC sheathed wire, used for Neon sign.
183 NRN Rubber insulated chloroprene sheathed wire, used for Neon sign.
184 NRV As same as NRN, but PVC sheathed.
185 NV PVC insulated wire used for Neon sign.
186 OC Out-door XLPE insulated wire.
187 OE As same as OC, but PE insulated.
188 OF Oil-filled cables.
189 OF- Series OF cables.
190 OFC Oxygen free copper conductor.
191 OPGW Optical fiber Ground Wire.
192 OW Out-door weather-proof PVC insulated wire.
193 PAZE Belt-paper insulated Al jacket PE anti-corrosion cables.
194 PAZN As same as PAZE, but chloroprene anti-corrosion.
195 PDB Power high voltage drop butyl rubber insulated wire.
196 PDBN As same as PDB, but has chloroprene sheathed wire.
197 PDC As same as PDB, but XLPE insulated.
198 PDE As same as PDC, but PE insulated wire.
199 PDN As same as PDC, but chloroprene insulated wire.
200 PDP As same as PDC, but EPR insulated wire.
201 PDRN As same as PDP, but rubber insulated chloroprene sheathed cable.
202 PDRV As same as PDRN, but PVC sheathed cable.
203 PDV As same as PDC, but PVC insulated wire.
204 PE EPR rubber insulated PE sheathed cables.
205 PH Power overhead transmission hard drawn copper conductor.
206 PN EPR insulated chloroprene sheathed cable.
207 PNCT As same as PN, but grade 1 - 4 cabtyre cable.
208 POF Pipe type high pressure oil filled cables.
209 PUFC Power under-carpet flat cables.
210 RAB Rubber insulated asbestos braid wire.
211 RB Rubber insulated wire.
212 RBN Butyl rubber insulated chloroprene sheathed for vehicle.
213 RBNM As same as RBN, but multi core.
214 RL Rubber insulated lead jacket cable.
215 RLF As same as RL, but flat type.

순위 약호 내용
216 RLTA As same as RL, but steel tape armoured.
217 RLWA As same as RL, but steel wire armoured.
218 RN Rubber insulated chloroprene sheathed cable.
219 RNCT As same as RN, but cabtyre cable grade 1 ~ 4.
220 RNCTF As same as RNCT, but flat type cord.
221 RNCTFK As same as RNCT, but round type cord.
222 RPN EPR insulated chloroprene sheathed for vehicle.
223 RRN As same as RPN, but rubber insulated.
224 RRNM As same as RRN, but multi-core.
225 RT Round type hard drawn trolley wire.
226 RT-Ag As same as RT, but copper conductor is involved 0.08% Ag.
227 RVCT Rubber insulated PVC cabtyre cable.
228 RVCTF As same as RVCT, but flat type cord.
229 RVCTFK As same as RVCT, but round rype cord.
230 SA Supper annealed copper conductor.
231 SAB Single asbestos braid copper wire.
232 SD Self-supported dustrivbution wire.
233 SEN Signal PE insulated chloroprene sheathed cable.
234 SEV As same as SEN, but PVC sheathed cable.
235 SEVTA As same as SEV, but steel tape armoured.
236 SF Rubber insulated single cord.
237 SGB Single glass braid wire.
238 SGC Single glass covered wire.
239 SHVVF 600V supper-heat resistant PVC insulated & sheathed flat type cable.
240 SHVVR As same as SHVVF, but round type cable.
241 SI- Aluminium alloy wire.
242 SL Separately leaded paper insulated cable.
243 SL- As same as SL, but armour or anti-corrosion type is different.
244 SMI Single MI cable.
245 SN-ACSR As same as ACSR, but anti-adhesion snow in winter.
246 SP Single ships cable.
247 SRN Signal rubber insulated chloroprene sheathed cable.
248 SSC Single silk covered copper conductor.
249 SVV Signal PVC insulated & sheathed cable.
250 SVV-SS As same as SVV, but self-supported cable.
251 SVVTA As same as SVV, but steel tape armoured.
252 SW- Internal devices signal telephone cables.
253 SY Equipment control & signal PVC wire. used for ships.
254 SYP ips equipment control & signal internal devices.
255 TA Tinned annealed copper conductor.
256 TACSR As same as ACSR, but Al is thermo-resistant Al-alloy.
257 TAI Thermo-resistant Al-alloy wire & cable.
258 TB- 3.3KV three-core butyl rubber insulated chloroprene sheathed cable.

순위 약호 내용
259 TBC Tin-coared braided copper conductor.
260 TGT Trapezoidal grooved trolley wire.
261 TH Tin-coated hard-drawn copper conductor.
262 TIV Telephone in door PVC insulated flat wire.
263 TJ- Telephone jumper wire & cable.
264 TMI Three core MI cable.
265 TOEY Telephone PE insulated nylon jacketed out-door wire.
266 TOV Telephone out door PVC insulated wire.
267 TOV-SS As same as TOV, but self-supported.
268 TP- Ships cable, EPR insulated and PVC or chloroprene sheathed.
269 TQ- Telephone quad type cable.
270 TSR- Triple silicone rubber insulated cable.
271 TTY 250V PVC insulated & amp; sheathed cable used for ship.
272 TVCC Telephone PVC insulated & cotton covered wire.
273 TVCCX Television camera cable.
274 TVEF TV received PE insulated flat cable.
275 TVS Telephone PVC insulated shielded wire.
276 UHF Ultra high frequency received feeder cord.
277 VCT PVC cabtyre cable.
278 VCTF As same as VCT, but cord.
279 VCTFK As same as VCT, but long-round type.
280 VFF PVC insulated flat cord used for equipment devices.
281 VKF As same as VFF, but long-round type.
282 VRF As same as VKF, but round type.
283 VSF Single PVC insulated cord used for equipment devices.
284 VSRF As same as VSF, but solid type round cord.
285 VTF As same as VSF, but twist type.
286 VV 600V PVC insulated & sheathed cable. (involved VVR & VVF)
287 VVF As same as VV, but flat type.
288 VVMAZV As same as VV, but steel corrugated armoured.
289 VVR Same VV, but round type.
290 WBNWA Butyl rubber insulated chloroprene sheathed single steel wire armoured used for under-water.
291 WBWA same as WANWA, but non-sheathed cable.
292 WCT Welding M/C lead rubber insulated cabtyre cable.
293 WCVWA As same as WANWA, but XLPE insulated PVC sheathed.
294 WCWA As same as WBWA, but XLPE insulated.
295 WEVWA As same as WCVWA, but PE insulated.
296 WEWA As same as WCWA, but PE insulated.
297 WNCT Welding M/C lead chloroprene cabtyre cable.
298 WPWA Belt-paper insulated lead jacket single galvanized steel wire armoured cable.
299 WOA Wire of annealed copper.
300 WOF- Oil filled cable, but used in the water.

순위 약호 내용
301 WOH Wire of hard drawn copper.
302 WR Wire rod of copper of aluminium.
303 WRCT Welding M/C holder natural rubber insulated cabtyre cable.
304 WRNCT Welding M/C holder natural rubber insulated cabtyre cable.
305 XB Braided wire used for X-ray.
306 XECX As same as ECX, but used for power line carrier transmission.
번호 제목 등록인 등록일 추천수 조회수 비고
985 [기사실기] 결상이란? (0) 전기스쿨 2024-10-07 34 364
984 [기사실기] 기준충격절연강도 (0) 전기스쿨 2024-08-12 66 566
983 [기사실기] 기전력을 E로 표기하는 이유 (0) 김대호 2024-03-26 123 1325
982 [기사실기] LS ( Line switch : 선로개폐기 ) (0) 전기스쿨 2024-03-19 181 1381
981 [기사실기] Sectionalizer( 자동선로구분개폐기) (0) 전기스쿨 2024-03-19 183 1070
980 [기사실기] ASS(Automatc section switch= 자동고장구분개폐기) (0) 전기스쿨 2024-03-19 154 1190
979 [기사실기] 특고애자교체 (0) 전기스쿨 2024-03-17 162 863
978 [기사실기] 고압선에서 눈 제거하기 (0) 전기스쿨 2024-03-14 169 921
977 [기사필기] 반작용 전동기 (2) 전기스쿨 2023-07-31 186 1588
976 [기사실기] disconnector 디스커넥터 / 피뢰기용 단로기 (0) 전기스쿨 2022-10-19 237 3486
975 [기사실기] %임피던스법과 옴법으로 구한 단락전류 (1) 김대호 2022-10-19 249 2991
974 [기사실기] VC(VACUUM CONTACTOR) 고압 진공전자접촉기 (0) OMM 2022-10-17 255 3505
973 [기사실기] 변압기 용량에 따른 전력용콘덴서 용량의 선정 (2) 전기스쿨 2022-08-19 247 6688
972 [기사실기] 2020년 기사 1회 견적 등의 증가는 매 1등 증가시 마다의 ...질문QNA (0) 전기스쿨 2022-08-12 261 1873
971 [기사실기] 전선관 및 전선의 규격 (0) 전기스쿨 2022-07-23 164 4654
970 [기사실기] 변류기의 과전류정수와 과전류강도의 의미 (0) 김대호 2021-12-28 202 8601
969 [기사실기] ACSR 규격 (1) 전기스쿨 2021-11-11 156 3253
968 [기사실기] 비율의 표현 (0) 김대호 2021-10-09 183 4010
967 [기사실기] 철탑 조류퇴치기 풍차식 (0) 김대호 2021-10-04 198 2587
966 [기사실기] TR 트랜지스터 동작 (0) 김대호 2021-10-03 167 2513
추천
목록
회사소개 이용약관 개인정보취급방침 이메일주소무단 수집거부 광고문의 도서배송 관리자쪽지 찾아오시는길
사이트 이용문의 : 0505-233-3314 FAX : 02-6442-6402 이메일주소 : pekor@naver.com 대표 : 강명아
주소 : 서울특별시 서초구 효령로 41, 1층 통신판매등록번호 : 2010-서울서초-0491
사업자등록번호 : 114-90-85522 스카이미디어(교육청 평생교육시설) 개인정보관리책임자 : 강명아

Since2004, Copyright ⓒ 2024 스카이미디어 / 전기스쿨 All Rights Reserved. Ver 3.4
